StarCraft II Quarkus Agent — Phase 1: Wiring Real SC2

Date: 2026-04-06 Type: phase-update

Protoss Stalker

What we were trying to achieve: prove the real SC2 wiring matches the mock contract

Phase 1 had one job: implement sc2.real — the real ocraft-backed implementations of the three CDI interfaces (SC2Client, GameObserver, CommandDispatcher) — and prove they satisfy the same contracts as the mock. No intelligence changes. No new plugin logic. Just swap the implementation family and see if the pipeline still runs.

We used the same subagent-driven approach as Phase 0: fresh Claude instance per task, two-stage review (spec then code quality) before moving on.

The two-loop architecture — and why it matters

Before writing a line of code I had to settle one architectural question. ocraft-s2client is callback-driven: S2Agent.onStep() fires every SC2 frame (~22fps) and you must send commands within that callback. Our @Scheduled intelligence pipeline runs at 500ms. These two clocks can’t share a thread.

The solution: IntentQueue as the handoff. The @Scheduled pipeline reads game state, runs CaseEngine, and writes typed intents to the queue. ocraft’s onStep() drains the queue and sends those intents to SC2 — within the callback, as required. Two independent loops, one thread-safe queue between them.

RealCommandDispatcher.dispatch() is a no-op. The dispatching happens in onStep(), not in our scheduler. This was the clearest evidence the architecture was right: the mock dispatcher mutated SimulatedGame directly, and the real dispatcher doing nothing was the correct behaviour.

What ocraft actually looks like

The plan was written from documentation and the Phase 0 mock. Implementation found four surprises in the actual 0.4.21 API.

obs.getUnits() returns List<UnitInPool> — not List<Unit>. The actual unit is accessed via .unit() on the wrapper. unit.getType() returns a UnitType interface, not the Units enum. unit.getHealth() and getHealthMax() return Optional<Float>. unit.getTag() returns a Tag object needing .getValue().

The translation ends up looking like this:

for (UnitInPool uip : obs.getUnits()) {
    Unit unit = uip.unit();

    // getType() returns UnitType interface — pattern match to get the enum
    Units unitEnum = (unit.getType() instanceof Units u) ? u : Units.INVALID;

    // getHealth()/getHealthMax() return Optional<Float>
    int health    = (int) unit.getHealth().orElse(0f);
    int maxHealth = (int) unit.getHealthMax().orElse(0f);

    // getTag() returns Tag wrapper — call getValue()
    String tag = String.valueOf(unit.getTag().getValue());
}

None of these are in the ocraft README. All four surprises are now in the knowledge garden as one entry.

The debug restriction that changed SC2BotAgent

The most interesting discovery came from SC2DebugScenarioRunner. The plan said: get the SC2BotAgent reference and call agent.debug().debugCreateUnit(...). The subagent hit a runtime NPE immediately.

agent.debug() accesses an internal controlInterface that is only initialised inside the ocraft game loop. Calling it from a REST handler — even after the game has started — throws a NullPointerException with no helpful message.

The fix emerged cleanly:

// SC2BotAgent — queue commands externally, flush in onStep()
private final ConcurrentLinkedQueue<Runnable> pendingDebugCommands
    = new ConcurrentLinkedQueue<>();

public void enqueueDebugCommand(Runnable command) {
    pendingDebugCommands.add(command); // safe from any thread
}

@Override
public void onStep() {
    Runnable cmd;
    boolean hadCommands = false;
    while ((cmd = pendingDebugCommands.poll()) != null) {
        cmd.run();       // debug() is safe here — we're in the game loop
        hadCommands = true;
    }
    if (hadCommands) debug().sendDebug();
    // ... observation storage, intent dispatch ...
}

// REST handler / scenario runner — no knowledge of onStep() required:
agent.enqueueDebugCommand(() ->
    agent.debug().debugCreateUnit(Units.PROTOSS_STALKER, 1, Point2d.of(22f, 20f), 2));

The queue is the interface. The caller doesn’t need to know about the constraint. Claude flagged this as DONE_WITH_CONCERNS, which is exactly what that status is for.

One remaining limitation: ocraft 0.4.21’s DebugInterface has no debugSetMinerals(int). Only debugGiveAllResources() exists at the high-level API. The set-resources-500 scenario maxes out resources rather than setting exactly 500 minerals. Precise resource setting would require raw protobuf — deferred.

What’s there now

Seven classes in sc2/real/. All mock beans gained @UnlessBuildProfile("sc2") — in the sc2 profile, exactly one implementation of each interface is active. AgentOrchestrator uses Instance<SimulatedGame> so it compiles in both profiles. All Phase 0 tests still pass.

Task 9 is still open: start SC2, run mvn quarkus:dev -Dquarkus.profile=sc2, and watch it connect. That one requires actual hands on a keyboard.
